Manufacturer: NXP
Product Category: Audio Amplifiers
Product: Audio Amplifiers
Class: Class-D
Output Power: 420 W
Mounting Style: Through Hole
Type: 1-Channel Mono or 2-Channel Stereo
Package / Case: DBS23P
Audio - Load Impedance: 8 Ohms
THD plus Noise: 0.03 %
Supply Voltage - Max: 42.5 V
Supply Voltage - Min: 12.5 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Packaging: Tube
Brand: NXP Semiconductors
CMRR - Common Mode Rejection Ratio: 75 dB
Description/Function: Speaker
Dual Supply Voltage: +/- 41 V
Gain: 36 dB
Height: 12.2 mm
Input Type: Differential
Length: 30.4 mm
Maximum Dual Supply Voltage: +/- 42.5 V
Minimum Dual Supply Voltage: +/- 12.5 V
Number of Channels: 2 Channel
Operating Supply Current: 65 mA
Output Current: 12 A
Output Signal Type: Differential, Single
Product Type: Audio Amplifiers
Subcategory: Audio ICs
Supply Current - Max: 60 mA, - 75 mA
Supply Type: Dual
Width: 4.6 mm
Unit Weight: 6.154 g
